Wellington Sheep Shearing System Worm-Drive

single stage sheep shearing system with worm drive, handpiece and two blade sets
ideal for sheep farmers who want to shear their flocks themselves

Ref. no.	PU	Pallet
18150	1	24 PAL

Technical data	Voltage	Mains frequency	Power	Stroke rate	Dimensions
18150	220 V - 240 V	50 Hz - 60 Hz	370 W	approx. 2800 strokes/min	39 cm x 29 cm x 22 cm

1 x sheep shearing system

1 x flexible shaft

1 x Wellington handpiece

2 x upper blade (18140)

2 x lower blade (18141)

Item. No.	Description	18150
BH139	Cover Cap f.18155	x
BM003	flange for motor	x
BM102	flexible shaft outside for	x
BH103	clamping claw left side	x
BH104	clamping claw right side	x
BH105	return spring	x
BH106	screw for blade (2 pcs)	x
BH107	clevis	x
BH108	bolt return spring	x
BH109	pressure pin	x
BH110	Rotary Sleeve	x
BH111	safety screw	x
BH112	pressure bushing	x
BH113	regulating nut	x
BH114	safety ring for regulating nut	x
BH115	spherical head cover	x
BH116	spherical head screw	x
BH117	nut for spherical head screw	x
BH118	clevis for Wellington	x
BH119	lubricating cap	x
BH120	excentric roll	x
BH122	Spring Seal	x
BH127	Joint Piece Spring	x
BH128	gear	x
BH129	Outer joint f.18157	x
BH133	Spring	x
BH134	spring cover	x
BH137	Circlip	x
BH300	ball bearing for handpiece	x
BH301	ball bearing rear 6000Z	x
BH321	crank spindle f.18156	x
BH323	inner joint for handpiece	x
BH324	long bush for hand piece	x
BH325	short bush for hand piece	x
BH331	joint guard for handpiece	x
BHM3X6	screw M3x6	x
BM005	Motor 370W for 18150	x
BM006	Switch housing for 18150	x
BM007	motor protection switch	x
BM008	Switch for 18150 Version2021	x
BM009	cable 2m for 18150	x
BM010	bracket with ring for 18150	x
BM011	Metal case for 18150	x
BM100	flexible shaft 1675mm for	x
BM101	core of bending wave	x
BM103A	Spline (M8) for Flexible Shaft	x
BM104	steel sleeve	x
BM106	connection case	x
BH141	Handle	x
BH142	Drive Shaft, type Worm Drive	x
