Power Shock B 500 plus

extremely powerful 9 volt dry battery device
perfectly suited for horse and cattle paddocks
increased output power and AUTO mode => minimal energy consumption through optimised, autonomous adjustment of the output power to the fence length and status
battery unit for long fences and light vegetative growth
up to max. 0.6 Joules in 12 V mode

allows for alternative operation with 12 Volt battery
5-year warranty

Fence control LED and separate battery warning indicator

Items

Ref. no.	PU		Pallet
372030	1	1	54 PAL	54 PAL

visual check for fence insulation and battery voltage
allows for optional operation with 12 V battery – with deep discharge protection
robust, impact-resistant, UV-resistant and weather-resistant housing thanks to the use of high-quality plastics
innovative closure technology
easy handling
very bright, clearly visible LED light
corresponds to applicable EU safety standards

Model	Ref. no.	Stored Energy		max. discharge energy		max. voltage		Voltage in Open Circuit		Voltage at 500 Ohms		theoretical fence length as per VDE		max. fence length without vegetation		max. fence length with medium vegetation		max. fence length with high vegetation		Qty 1 m earth posts		Power Consumption
B 500 plus	372030	0.64 J	0.64 J	0.5 J	0.5 J	10000 V	10000 V	9500 V	9500 V	3700 V	3700 V	16 km	16 km	9 km	9 km	6 km	6 km	1.8 km	1.8 km	1	1	17 mA - 64 mA	17 mA - 64 mA

1 x fence unit
1 x earth rod
1 x fence / ground connector cable
1 x warning sign

Preview image	Item. No.	Description	372030
	AKO265805	Rotary Knob B-SI with Scale	x
	AKO268376	Knurled nut type D M8x1 blk.	x
