Mobil Power AD 3000 digital

Digital Display Readout and LED Lights for Fence and Battery Voltage

Recommended solar module: Item number 375256 (25 Watt) - mounting directly on the device handle

Ref. no.	PU		Pallet
372291	1	1	33 PAL	33 PAL

Ref. no.	Description	Width	Depth	Height	PU
375256	Solar Panel without charge controller	37.5 cm	2 cm	56 cm	1

with 12 Volt full discharge protection
The shock strength can be steplessly adjusted with the manual controller (1 - 20)
Can be operated via a 230-V power pack (371012 - not included)
integrated solar charge controller
digital display to indicate the fence voltage, battery voltage and power level
robust, impact-resistant, UV-resistant and weather-resistant housing thanks to the use of high-quality plastics
large battery container for the 12-Volt battery
microprocessor controlled
very bright, clearly visible LED light
corresponds to applicable EU safety standards
Connection cable not included in the scope of delivery

Model	Ref. no.	Stored Energy		max. discharge energy		min. discharge energy		max. voltage		Voltage in Open Circuit		Voltage at 500 Ohms		theoretical fence length as per VDE		max. fence length without vegetation		max. fence length with medium vegetation		max. fence length with high vegetation		Approx. Number of Electrifiable Nets		Qty 1 m earth posts		Power Consumption
AD 3000 digital	372291	5.7 J	5.7 J	3 J	3 J	0.5 J	0.5 J	10800 V	10800 V	9800 V	9800 V	6000 V	6000 V	90 km	90 km	30 km	30 km	10 km	10 km	4 km	4 km	12	12	3	3	17 mA - 290 mA	17 mA - 290 mA
