Duo Power X 6000 smart

12/230 Volt DUO fence device – maximum flexibility combined with powerful output energy
ideal for horses, cattle, sheep, goats and deterring wild boars and wolves
can be used with medium to heavy vegetative growth
directly integrated cloud connection
distance-neutral control (ON/OFF, GPS tracking) and monitoring of fence systems by smartphone
permanently free mobile data transfer to the app

multi-colour LED bar graph display for output voltage and battery control

recommended solar module: 375559 (55 Watt), connection directly to the 12-Volt battery, optionally with ground anchor 442382 or fixing set 442386 for metal box

Important: mounting in the metal battery case can impair the radio connection to the LTE network.

Items

Ref. no.	PU		Pallet
372876	1	1	72 PAL	72 PAL

optimised consumption thanks to energy saving mode – saves battery power in fences in good condition. Also intelligent battery management for when battery voltage decreases.
deep discharge protection for the 12 volt battery
microprocessor controlled
High safety in line with the latest safety standards
incl. free app download
with High/Low/OFF switch for 2 different output powers
robust, impact-resistant, UV-resistant and weather-resistant housing thanks to the use of high-quality plastics
Solar backup possible
integrated hanging device for wall mounting
corresponds to applicable EU safety standards

Model	Ref. no.	Stored Energy		max. discharge energy		max. voltage		Voltage in Open Circuit		Voltage at 500 Ohms		theoretical fence length as per VDE		max. fence length without vegetation		max. fence length with medium vegetation		max. fence length with high vegetation		Approx. Number of Electrifiable Nets		Qty 1 m earth posts		Power Consumption
X 6000 smart	372876	7.5 J	7.5 J	5 J	5 J	12000 V	12000 V	10000 V	10000 V	9000 V	9000 V	130 km	130 km	40 km	40 km	11 km	11 km	6 km	6 km	20	20	3	3	42 mA - 368 mA	42 mA - 368 mA

1 x fence unit
1 x 230 volt power pack (371030)
1 x 12-Volt connection cable (E268739)
1 x fence / ground connector cable
1 x warning sign

CE-Declaration of Conformity
