Duo Power X 4000

12 V / 230 V DUO device with extremely high output power
for longer fences, also with vegetation
ideal for use also with strong animals and for keeping wild boar and wolves at bay

with High/Low/OFF switch for 2 different output powers
5-year warranty

multi-colour LED bar graph display for output voltage and battery control

recommended solar module: Item number. 375251 (25 Watt), connection directly to the 12-Volt battery, mounting e.g. on a metal box or: Item number 375559 (55 Watt), connection directly to the 12-Volt battery plus ground anchor kit 442382 or fixing set 442386 for metal box

Items

Ref. no.	PU		Pallet
372874	1	1	88 PAL	88 PAL

Accessories

Ref. no.	Description	Width	Depth	Height	PU
375251	Solar Panel incl. charge controller	37.5 cm	2 cm	56 cm	1

optimised power consumption thanks to energy-saving mode
deep discharge protection with 12 V operation
microprocessor controlled
plug connector with screw fuse
robust, impact-resistant, UV-resistant and weather-resistant housing thanks to the use of high-quality plastics
integrated hanging device for wall mounting
very bright, clearly visible LED light
corresponds to applicable EU safety standards
(suitable for metal box 44656 and 44650)

Model	Ref. no.	Stored Energy		max. discharge energy		max. voltage		Voltage in Open Circuit		Voltage at 500 Ohms		theoretical fence length as per VDE		max. fence length without vegetation		max. fence length with medium vegetation		max. fence length with high vegetation		Approx. Number of Electrifiable Nets		Qty 1 m earth posts		Power Consumption
X 4000	372874	5.5 J	5.5 J	4 J	4 J	11900 V	11900 V	10300 V	10300 V	8400 V	8400 V	110 km	110 km	35 km	35 km	9 km	9 km	4 km	4 km	16	16	2	2	117 mA - 300 mA	117 mA - 300 mA

1 x fence unit
1 x 230 volt power pack (371023)
1 x 12-Volt connection cable (E268739)
1 x ground connector cable
1 x fence connector cable
1 x warning sign (44623)

Item. No.	Description	372874
AKO268739	Connector Cable 12 V for DUO	x
AKO268861	Knurled nut M8 BIG black	x
AKO268862	Knurled nut M8 BIG red	x
