Duo Power X 1000

optimised power consumption thanks to energy-saving mode

deep discharge protection with 12 V operation

microprocessor controlled

plug connector with screw fuse

robust, impact-resistant, UV-resistant and weather-resistant housing thanks to the use of high-quality plastics

integrated hanging device for wall mounting

very bright, clearly visible LED light

corresponds to applicable EU safety standards

(suitable for metal box 44656 and 44650)

Function control LED and visual battery warning indicator

recommended solar module: item number 375151 (15 Watt), connection directly to the 12-Volt battery, mounting e.g. on a metal box

Ref. no.	PU	Pallet
372871	1	88 PAL

Ref. no.	Description	Width	Depth	Height	PU
375151	Solar Panel incl. charge controller	37.5 cm	2 cm	37 cm	1

Model	Ref. no.	Stored Energy	max. discharge energy	max. voltage	Voltage in Open Circuit	Voltage at 500 Ohms	theoretical fence length as per VDE	max. fence length without vegetation	max. fence length with medium vegetation	max. fence length with high vegetation	Approx. Number of Electrifiable Nets	Qty 1 m earth posts	Power Consumption
X 1000	372871	1.6 J	1 J	10500 V	9000 V	4400 V	35 km	10 km	1.5 km	0.8 km	4	1	115 mA

1 x fence unit

1 x 230 volt power pack (371023)

1 x 12-Volt connection cable (E268739)

1 x ground connector cable

1 x fence connector cable

Preview image	Item. No.	Description	372871
	AKO268861		x
	AKO268862		x
