Drinking Bowls K50

  • water bowl made from high-quality plastic
  • lockable tongue (separate accessory)
  • 4-hole fastening
  • suitable for 1/2" and 3/4" connections
  • Fastening material not included
  • for wall and pipe mounting

suitable for 1/2" and 3/4" connections

Items
Ref. no.DescriptionColourWater connectionCapacityMOQPieces / unitPUPallet
225031Kerbl designgreenG 1/2" / G 3/4"2.2 L11120 PAL120 PAL
225032Kerbl designolive greenG 1/2" / G 3/4"2.2 L11120 PAL120 PAL
225030neutral presentationblueG 1/2" / G 3/4"2.2 L11120 PAL120 PAL
225033neutral presentationblackG 1/2" / G 3/4"2.2 L2 pieces2 / box1/21/2160 PAL160 PAL
Accessories
Ref. no.DescriptionColourMaterialConnectionFrame heightPU
221971Guard Size 2 hot-dip galvanised metal 20 cm1/4
223426Valve high-pressure brass  1/20/200
22501tube mounting bracket with stabilising plates in pairs metal  1/25
2250341Panel Lock for Drinking Trough K50    1/50/500
225034Nose Paddle Plastic  1/40
2218606Sealing plugblackPlastic3/4" 1/200

Technical dataDimensions (W x D x H)Connection optionWater flow rateFlow rateWeight
22503121 cm x 30,2 cm x 17 cmfrom above or below3-way adjustable7.5 L/min - 11 l/min (3 bar)950 g
22503221 cm x 30,2 cm x 17 cmfrom above or below3-way adjustable7.5 L/min - 11 l/min (3 bar)950 g
22503021 cm x 30,2 cm x 17 cmfrom above or below3-way adjustable7.5 L/min - 11 l/min (3 bar)950 g
22503321 cm x 30,2 cm x 17 cmfrom above or below3-way adjustable7.5 L/min - 11 l/min (3 bar)950 g

Preview imageItem. No.Description225031225032225030225033
High-pressure valve replacem.223426High-pressure valve replacem.xxxx
 225029Axle with Nuts for 225030,xxxx
Spare Tongue Plstic Drnkng Bwl225034Spare Tongue Plstic Drnkng Bwlxxxx
 2218606Sealing Plugs plastic 3/4''xxxx
