Aesculap Sheep Shearing Machine Econom II

The sheep clipper in a class of its own with the detailed quality you'd expect from a premium manufacturer:

high shearing speed due to high number of strokes
glides well thanks to high-power motor
low heat thanks to high air throughput
ergonomic handling thanks to slim housing and balanced weight distribution
service-friendly design
tool-free filter changes – easy carbon replacement – plug-in plate
integrated electronic start control and overload protection
uniform and long-lasting cut quality thanks to low-wear shearing blades
shearing blades made from abrasion-resistant carbon steel can be repeatedly reground

200 W DC = 400 W AC

Items

Ref. no.	Description	Colour	Teeth lower/upper blade	PU		Pallet
GT494	incl. shearing blade set (GT588, GT578)	blue	13 / 4	1/5	1/5	80 PAL	80 PAL

Accessories

Ref. no.	Description	suitable for	Lower blade teeth	Upper blade teeth	Cutting length	PU
GT369	Blade set incl. shearing blade set (GT588, GT578)					1/12
GT578	Shearing Blade for Sheep Econom Upper Blade, BB-4.5 mm	universal		4		1/10/100
GT588	Shearing Blade for Sheep Econom Lower blade	GT824, GT494	13		3.5 mm	1/10/100
GT594	Shearing Blade for Sheep Econom Lower blade	universal	13		3.5 mm	1/10/100

Technical data	Voltage	Output	Drive	Drive	Stroke rate	Sound pressure level	Cable length	Weight	Protection class
GT494	230 V	200 W DC	DC motor	Spur gear	approx. 2750 strokes/min	76 dB	5 m	1200 g	II

1 x clipper Econom II
1 x upper blade (GT578)
1 x lower blade 3.5 mm (GT588)
1 x Aesculap oil (GT604)
1 x Durable plastic case

Item. No.	Description	GT494
GT604	Clipper oil 90ml	x
GT074040	Ball bearing	x
GT369208	Spring	x
GT369209	Pressure rod	x
GT369213	Eccentric shaft	x
GT369214	Bearing bush	x
GT369312	Pur gear with shaft	x
GT369801	Housing bottom section	x
GT369814	Repair set bevel gear	x
GT374208	Carbon brush	x
GT374806	Brush holder, mounted	x
GT474205	Diaphragm	x
GT474206	Slide knob	x
GT474210	Nut	x
GT474211	Safety unit plug switch	x
GT474227	Bearing bush	x
GT474242	Sliding pin UL	x
GT474243	Motor Cap UL	x
GT474819	Suitcase blows up for shearing	x
GT474820	Magnetic frame, complete	x
GT474830	Circuit board complete, 230V	x
GT474841	Motor casing UL	x
GT474842	Storage tray UL	x
GT474844	Filter UL	x
GT474860	Rotor packed, 230V	x
GT494306	Metallic small cushion	x
GT586139	Compression bearing brush	x
GT586239	Spring ring	x
GT620021	Nut hexagon, DIN439,	x
GT620023	Spring tooth washer	x
GT620203	Rocking lever bolt	x
GT620208	Nut M18,0x1,0	x
GT620306	Nut	x
GT630015	Screw to shut	x
GT630204	Retaining spring	x
GT669100	Housing Cover	x
GT669205	Rocker Arm	x
GT669206	Clamping claw, left	x
GT669207	Clamping claw, right	x
TA003544	front bearing for 35104 and	x
TA003816	Set screw, hexagon socket,	x
TA003817	Hexagon nut, DIN439, M5,0x0,8	x
TA003834	Hexagon nut M3,0x0,5	x
TA004029	Rubber ring (TE230)	x
TA007573	Cylinder Screw M4x16, DIN84	x
TA007707	Slide switch, 230V	x
TA008529	Cable sleeve	x
TA008530	Cable Clamp	x
TA008542	felt ring	x
TA008588	Cylinder screw M3x8	x
TA009222	Screwdriver	x
TA010017	Housing screw for GT474	x
TA010018	Safety device	x
TA010197	Mains cable with plug	x
TA010349	Screw thread-forming,	x
TA012140	PT-Torx Screw	x
TA015527	Torx Screw M 3 x 8 TX	x
